DPLVD-1014

Low Voltage Load Disconnect

Price $

Price Break/Unit Price


Request Lead Time

REQUEST MODIFICATION

Submit Request

Description

The DPLVD-1014 Low Voltage Load Disconnect (LVLD) device senses battery voltage and automatically disconnects either the battery or load when the voltage drops to a preset critically low level.

The DPLVD-1014 reconnects the battery or load when the voltage returns to the preset desired voltage level.

The DPLVD-1014 is a smart programmable device that allows for soft configuration adjustments, enabling specific voltage levels for disconnecting and reconnecting and customizing various alarm functions.

The DPLVD-1014 provides power for both audible and visual LED warning alarms.

The DPLVD-1014 helps prolong battery life by preventing damage due to excessive low-level discharging.

Its small size and lightweight design make for easier and more discrete mounting, optimizing the use of available space and improving wire routing.

The DPLVD-1014 is fully sealed with encapsulation and has an IP67 protection class, ensuring it can withstand exposure to harsh environments.

General Specifications

Input Type

Input Voltage AC

N/A
Input Voltage DC

7 - 23V
PFC

N/A
Efficiency

N/A
Output Voltage

11.4 - 12.4V
Output Power

N/A
Number of Outputs

N/A
Temperature Range

N/A
Package Type

Enclosed
Package Size

N/A
Market Application

Military
Safety Approval

N/A
